High speed RGBW linear CCD sensor of TOSHIBA co, 5400 pixels with excellent scanning rate, able to detect the slightest differences upto 0.02mrn.
Innovative high-speed GOWIN FPGA processing platformed architecture supporting reverse sorting, re-sorting and size recognition methodology.
SMC or Korean ARK Filter and air cylinder with excellent durability and accuracy. Filtration 0.1um mm/s, fend off mist, oil tinny particles, giving ejector best protection.
12 inches HMI, resolution 1024x768, imbeded Windows 7 operating system, capable of online support and image capturing. More than 300 setting profiles storage, enable machine quick to read preset programmes.
Customized LED strips with prism configuration, making the light bright and even. The best brightness providing the best defects analysis.
SMC or Matrix High-frequency ejectors, Intelligent algorithm tracking, precise rejection 0.9ms response time.
Model | TCS 2T |
Main Power (kW) | 1.5 |
Air Consumption (m /min) | 1.2 |
Capacity (t/h) | 1.2 |
Net Weight (kg) | 615 |
Dimension (LxWxH) (mm) | 1330 x 1660 x 2185 |
Model | DCS-1200S-M |
Ejector | 120 |
Capacity | / |
Optimized Carryover | / |
Voltage (V) | AC380V / 50Hz |
Power | <5.5 |
Weight (Kg) | 1800(+10%) |
Dimension (LxWxH mm) | 4392x1928x2501 |
Model | TCS 7T |
Main Power (kW) | 7.5 |
Air Consumption (m /min) | 3.5 |
Capacity (t/h) | 5-10 |
Net Weight (kg) | 1650 |
Dimension (LxWxH) (mm) | 2985 x 1660 x 2185 |
Model | TCS 1T |
Main Power (kW) | 1 |
Air Consumption (m /min) | 0.6 |
Capacity (t/h) | 0.6-1 |
Net Weight (kg) | 400 |
Dimension (LxWxH) (mm) | 1030 x 1600 x 1950 |
Model | TCS 6T |
Main Power (kW) | 7.5 |
Air Consumption (m /min) | 3.2 |
Capacity (t/h) | 4-9 |
Net Weight (kg) | 1450 |
Dimension (LxWxH) (mm) | 2670 x 1660 x 2185 |
Model | DCS-6T |
Ejector | 384 |
Capacity | 5.0~8.0 |
Optimized Carryover | >100:1 |
Voltage (V) | AC220V / 50Hz |
Power | <5.2 |
Weight (Kg) | 1246(+5%) |
Dimension (LxWxH mm) | 2656x1619x2042 |
Model | DCS-2T160 |
Ejector | 160 |
Capacity | 1.5~3.2 |
Optimized Carryover | >100:1 |
Voltage (V) | AC220V / 50Hz |
Power | <2.5 |
Weight (Kg) | 570(+5%) |
Dimension (LxWxH mm) | 1330x1630x1550 |
Model | TCS 5T |
Main Power (kW) | 5 |
Air Consumption (m /min) | 2.8 |
Capacity (t/h) | 3-8 |
Net Weight (kg) | 1250 |
Dimension (LxWxH) (mm) | 2355 x 1660 x 2185 |
Model | TCS 4T |
Main Power (kW) | 5 |
Air Consumption (m /min) | 2.4 |
Capacity (t/h) | 3-6 |
Net Weight (kg) | 915 |
Dimension (LxWxH) (mm) | 2025 x 1660 x 2185 |
Model | TCS 3T |
Main Power (kW) | 3 |
Air Consumption (m /min) | 2 |
Capacity (t/h) | 2-2.5 |
Net Weight (kg) | 763 |
Dimension (LxWxH) (mm) | 1645 x 1660 x 2185 |
